Switching Power Supply DR-75

Switching Power Supply DR-75
Switching Power Supply DR-75
  • Categories:Din Rail series
  • MOQ:1
  • Brand:Trihero
  • FOB Port:Shanghai port, Ningbo port
  • Terms of Payment:Western Union, T/T, Paypal
  • Delivery Time:7 Working Days

Features:
For AC power supply input global
Protection characteristics: short circuit/overload/pressure
Air cooling
Can be installed DIN standards guide TS-35/7.5 or 15
Has the boot display (light emitting diode (led)
100% full load and machine test
Working frequency 50 KHz
One year warranty
Size: 55.5 * 125.2 * 100 mm (W * H * D)

model

DR-75-12

DR-75-24

HDR-75-48

output

Dc output voltage

12V

24V

48V

Output voltage tolerance

±2%

±1%

±1%

Rated output current

6.3A

3.2A

1.6A

Output current range

0-6.3A

0-3.2A

0-1.6A

Output power

76W

76.8W

76.8W

Ripple and the noise

100mVp-p

150mVp-p

240mVp-p

Dc voltage adjustable scope

17%

17%

10%

Start, rise time

1000ms,60ms/230VAC Loaded with 1800ms,60ms/115VAC Loaded with

Keep time

60ms/230VAC12ms/115VAC Loaded with

input

Input voltage range

85~264 VAC choose 47~63 Hz;120~370VDC

Exchange input current

1.6 A/115 V 0.96A/ 230 V

efficiency

76%

80%

81%

Impulse current

Cold start current 20A/115V 40A/230V

Leakage current

<1mA/240VAC

Protection characteristics

Overload protection

105%~150%

Protection way: constant current limiting automatic recovery

Overvoltage protection

120%~140%

Protection way: hiccups, auto recovery mode

High temperature protection

TSW1≥85℃±5℃,

Protection way: cut output, temperature down automatically restored

environment

Working temperature, humidity

-10℃~+60℃;20%~90 %RH

Keep temperature, humidity

-20℃~+85℃;10%~95 %RH

Vibrate resistance

10 ~ 500 Hz ac, 2 G 10 min. / 1 cycle time, 60 minutes, the axis

security

Compression sex

3: KVAC between input and output and input and output KVAC: 1.5 to 0.5: KVAC

Insulation resistance

Between the input and output, the input and output, and ground: 100 M / 500 VDC Ohms

Complies with the standards

Safety standards

符合UL508,TUV EN60950-1

EMC standard

EN55011,EN55022,EN61000-3-2,-3,EN61000-4-2,3,4,5,6,8,11,ENV50204,EN55024,EN61000-6-2

other

weight

0.6Kg

packaging

20pcs/13Kg/1.1CUFT

note

1. All the parameters in has not specified, all is in 230 VAC voltage input, rated load and 25 ℃ conditions measuring income value.

2. Ripple and noise voltage is in 20 MHz bandwidth oscilloscope take 12 inches twisted pair end with 0.1 mu and 47 u when capacitance measurement.

3. Tolerance is voltage setting error, the voltage adjustment rate and adjust the sum total of the current rate.

4. The power to consider as a device installed in final equipment, this equipment must be to make sure it’s EMC index.
